Name: TP-Link T2600G-52TS (TL-SG3452) L2 Managed Switch (48-Port, 48 10/100/1000Mbps)
Brand: TP-Link
SKU: T2600G-52TS (TL-SG3452)
Price: 2099.00 MYR
Availability: InStock

TP-Link T2600G-52TS (TL-SG3452) L2 Managed Switch (48-Port, 48 10/100/1000Mbps)

Description

PRODUCT DESCRIPTION

TP-Link T2600G-52TS (TL-SG3452) L2 Managed Switch

48-Port | 48 10/100/1000Mbps RJ45 Ports | 4 Gigabit SFP Slots

* Please Call for order to make sure stock are ready. *
* Images & product color may vary from actual products.*
*All Prices Exclude delivery/installation/activation fees.*

PACKAGE CONTENTS

Switches

ADDITIONAL INFORMATION

View Official Website

Warranty
- 3 Years TP-Link Warranty
- Manufactured and warranty provided by TP-Link

SPECIFICATIONS

Model	T2600G-52TS (TL-SG3452)
Hardware Features
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p
Interface	48 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) 4 1000Mbps SFP Slots 1 RJ45 Console Port 1 Micro-USB Console Port
Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) 1000BASE-X: MMF, SMF
Fan Quantity	Fanless
Power Supply	100~240VAC, 50/60Hz
Dimensions ( W x D x H )	17.32 * 8.7 * 1.73 in. (440 * 220 * 44 mm)
Mounting	Rack Mountable
Max Power Consumption	33.52W (220V/50Hz)
Max Heat Dissipation	114.37 BTU/h
Performance
Bandwidth/Backplane	104Gbps
Packet Forwarding Rate	77.4Mpps
MAC Address Table	16k
Jumbo Frame	9216 Bytes
Software Features
Quality of Service	Support 802.1p CoS/DSCP priority Support 8 priority queues Queue scheduling: SP, WRR, SP+WRR Port/Flow- based Rate Limiting Voice VLAN
L2 and L2+ Features	Static Routing DHCP Relay IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 14 aggregation groups, containing 8 ports per group) Spanning Tree STP/RSTP/MSTP BPDU Filtering/Guard TC/Root Protect Loopback detection 802.3x Flow Control L2PT
VLAN	Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs) Port/ MAC/Protocol-based/Private VLAN GARP/GVRP
Access Control List	L2～L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID Time Range Based
Security	IP-MAC-Port-VID Binding AAA* 802.1x and Radius Authentication DoS Defend Dynamic ARP inspection (DAI) SSH v1/v2 SSL v3/TLSv1 Port Security Broadcast/Multicast/Unknown-unicast Storm Control
IPv6 Applications	DHCPv6 Client Ping6 Tracert6 Telnet(v6) IPv6 SNMP IPv6 SSH IPv6 SSL Http/Https IPv6 TFTP IPv6 ACL IPv6 Interface IPv6 Routing DHCPv6 Relay DHCPv6 Snooping
Management	Web-based GUI and CLI management SNMP v1/v2c/v3,compatible with public MIBs and TP-Link private MIBs RMON (1, 2, 3, 9 groups) sFlow PPPoE Circuit ID DHCP Relay DHCP Server DHCP/BOOTP Client, DHCP Snooping, DHCP Option82 Dual Image CPU Monitoring Port Mirroring Time Setting: SNTP Integrated NDP/NTDP feature Firmware Upgrade: TFTP & Web System Diagnose: VCT SYSLOG & Public MIBS Password Recovery
Others
Certification	CE, FCC, RoHS
System Requirements	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux.
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*
