Name: Epson LQ-590IIN Dot Matrix Printer (24-pin, up to 487cps, 1+6 copies, USB and Parallel ports,Network)
Brand: Epson
SKU: LQ-590IIN
Price: 3539.00 MYR
Availability: InStock

Epson LQ-590IIN Dot Matrix Printer (24-pin, up to 487cps, 1+6 copies, USB and Parallel ports,Network)

-3 %

Description

PRODUCT DESCRIPTION

Epson LQ-590IIN Dot Matrix Printer

24-pins Impact Printer | Speed: up to 487cps | MTBF: 25,000 Power on Hours | USB and Parallel ports

* Please Call for order to make sure stock are ready. *
* Images & product color may vary from actual products.*
*All Prices Exclude delivery/installation/activation fees.*

PACKAGE CONTENTS

Dot Matrix Printer

ADDITIONAL INFORMATION

View Official Website

Warranty
- 1 year Epson Warranty
- Manufactured and warranty provided by Epson

SPECIFICATIONS

Model	Epson LQ-590IIN Dot Matrix Printer
Printing Technology	Print Method: Impact dot matrix Control Panel: 6 switches and 10 LEDs Print Direction: Bi-direction Control Code: ESC/P2, IBM PPDS Number of Pins: 24
Print Speed	Ultra High Speed Draft: 10 cpi: 550cps High Speed Draft: 10 / 12 cpi: 487 / 584 cps Draft: 10 / 12 cpi: 366 / 439 cps NLQ: 10 / 12 cpi: 121 / 145 cps
Reliability	Printhead life: 400 million strokes / wire Mean Print Volume Between Failure (MVBF): 50 million lines (except print head) Mean Time Between Failure (MTBF): 25,000 Power On Hours (POH) (25% Duty)
Print Characteristics	Character Sets: 1 Italic and 12 graphical character tables: Italic table, PC437 (US, StandardEurope), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC865 (Nordic), PC863 (Canadian-French), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC858, ISO 8859-15 Bitmap Fonts: 10, 12, 15 cpi Scalable Fonts: Epson Roman / Sans Serif / Roman T / Sans Serif H: 10.5pt., 8pt - 32pt. (every 2pt.) Barcode: EAN-13, EAN-8, Interleaved 2 of 5, UPC-A , UPC-E, Code 39, Code 128, POSTNET
Paper Path	Manual Insertion: Front or Rear in-Top out Push Tractor: Front or rear in, top out Pull Tractor: Front, rear or bottom in, top out
Paper Media	Cut Sheet (Single Sheet): Entry: Front Length: 100 - 364 mm (3.9 - 14.3”) Width: 100 - 257 mm (3.9 - 10.1”) Thickness: 0.065 - 0.14 mm (0.0025 - 0.0055”) Entry: Rear Length: 100 - 364 mm (3.9 - 14.3”) Width:100 - 257 mm (3.9 - 10.1”) Thickness: 0.065 - 0.14 mm (0.0025 - 0.0055”) Cut Sheet (Multi-part Forms): Entry: Front Length: 100 - 364 mm (3.9 - 14.3”) Width: 100 - 257 mm (3.9 - 10.1”) Thickness: 0.12 - 0.46 mm (0.0047 - 0.018”) Copies: 1 Original + 5 copies Continuous Paper (Single Sheet / Multi-part): Entry: Front, Rear, Bottom Length: 101.6 - 558.8 mm (4.0 - 22.0”) Width: 101.6 - 254 mm (4.0 - 10.0”) Thickness: 0.065 - 0.49 mm (0.0025 - 0.019”) Copies: Original + 6 copies Envelope (No.6): Entry: Rear Length: 92mm (3.6”) Width: 165mm (6.5”) Thickness: 0.16 - 0.52 mm (0.0063 - 0.0205”) Envelope (No.10): Entry: Rear Length: 105mm (4.1”) Width: 241mm (9.5”) Thickness: 0.16 - 0.52 mm (0.0063 - 0.0205”) Label (Base Sheet): Entry: Bottom Length: 101.6 - 558.8 mm (4.0 - 22.0”) Width: 100 - 148 mm (3.9 - 5.8”) Thickness: 0.16 - 0.19 mm (0.0063 - 0.0075”) Card: Entry: Front, Rear Length: 100 - 148 mm (3.9 - 5.8”) Width: 100 - 148 mm (3.9 - 5.8”) Thickness: 0.22mm (0.0087”) Roll Paper: Entry: Rear Diameter: 127mm (5”) Width: 216mm (8.5”) Thickness: 0.07 - 0.09 mm (0.0028 - 0.035”) Line Spacing: 4.23mm (1/6”) or programmable in increments of 0.0706mm (1/360”)
Electrical Specifications	Rated Voltage: AC 220 - 240 V Rated Frequency: 50Hz - 60Hz Electric Power Consumption: Operating: 49W Sleep Mode: 0.5W Power Off: 0.1W in power off mode
Options	Single Bin Cut Sheet Feeder C12C806372 Pull Tractor Unit C12C933761 Ribbon Cartridge C13S015589 High Capacity Cut Sheet Feeder C12C806382
Environmental Conditions (Operating)	Environmental Conditions (Operating) Temperature: 5 - 35 °C2 Humidty: 10 - 80% RH2
Acoustic Noise	Acoustic Noise: 55dB
Input Data Buffer	Input Data Buffer: 128KB
Interface	Interface: USB 2.0, Bi-directional parallel USB 2.0, Bi-directional parallel (IEEE-1284 nibble mode supported)
Acoustic Noise	Acoustic Noise: 55dB
Interface	USB 2.0, Bi-directional parallel (IEEE-1284 nibble mode supported), Serial, 100base-Tx wired LAN
Printable Columns	Pitch: 10cpi: 80 columns
Ribbon Cartridge	Standard: Fabric Ribbon Cartridge (Black) Ribbon Life: Approx. 5 million Characters*1
Supported OS and Applications	Printer Driver: Microsoft Windows XP / Vista / 7 / 8 / 10 Utility: Epson Status Monitor 3: Microsoft Windows XP / Vista / 7 / 8 / 10 Epson Setting Utility: Microsoft Windows XP / Vista / 7 / 8 / 10
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*

Epson LQ-590IIN Dot Matrix Printer (24-pin, up to 487cps, 1+6 copies, USB and Parallel ports,Network)

Specifications
Reviews

Dot-Matrix Specifications
Dot-Matrix Control Panel	6 switches and 10 LEDs
Dot-Matrix Print Direction	Bi-direction
Dot-Matrix Print Method	Impact dot matrix
Dot-Matrix Print Speed	columns, 612cps (high speed draft@10cpi)
Dot-Matrix Printhead Type	24 pins
Dot-Matrix Technology2	Dot Matrix printer
Dot-Matrix Additional Specs
Dot-Matrix Easy connectivity	USB 2.0, parallel, Serial, built in 100base-Tx wired LAN
Dot-Matrix Mean Time Between Failure	25,000 Power On Hours
Dot-Matrix Multi-part flexibility	1+6 copies
