Name: TP-Link ER7406 Routers (10G Port, 1 GB DDR4, 128 MB NAND)
Brand: TP-Link
SKU: ER7406
Price: 1149.00 MYR
Availability: InStock

TP-Link ER7406 Routers (10G Port, 1 GB DDR4, 128 MB NAND)

Description

PRODUCT DESCRIPTION

TP-Link ER7406 Routers

10G Port | 1 GB DDR4 | 128 MB NAND

* Please Call for order to make sure stock are ready. *
* Images & product color may vary from actual products.*
*All Prices Exclude delivery/installation/activation fees.*

PACKAGE CONTENTS

Router

ADDITIONAL INFORMATION

View Official Website

Warranty
- 3 Years TP-Link Warranty
- Manufactured and warranty provided by TP-Link

SPECIFICATIONS

Model	ER7406
HARDWARE FEATURES	Standards and Protocols • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP Interface • 1 Gigabit SFP WAN/LAN Port • 1 Gigabit WAN Port • 4 Gigabit LAN/WAN Ports • 1 USB 3.0 Port (supports USB LTE dongle and USB storage) Network Media • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) Fan Quantity Fanless Button Reset Button Power Supply 100-240VAC, 50/60Hz Flash 128 MB NAND DRAM 512 MB DDR4 LED PWR, SYS, SFP, USB, WAN(1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act) Dimensions ( W x D x H ) 11.6 × 5.5 × 1.7 in (294 × 140 × 44 mm) Protection 4 kV surge protection Enclosure Steel Mounting • Desktop • Rackmountable Max Power Consumption • 7.5 W (with USB 3.0 connected) • 4.5 W (without USB 3.0 connected)
PERFORMANCE	IPS Throughput TCP: 229 Mbps; UDP: 188 Mbps DPI Throughput TCP: 933 Mbps; UDP: 927 Mbps GRE • Unencrypted: 611.9 Mbps • Encrypted: 325.0 Mbps WireGuard VPN 341.3 Mbps Concurrent Session 150,000 New Sessions /Second 5,300 NAT (Static IP) 945.3 Mbps / 940.5 Mbps NAT(DHCP) 939.6 Mbps / 940.9 Mbps NAT(PPPoE) 943.6 Mbps / 940.9 Mbps NAT (L2TP) 880.1 Mbps / 859.0 Mbps NAT (PPTP) 855.0 Mbps / 907.2 Mbps IPsec VPN Throughput • ESP-SHA1-AES256: 617.1 Mbps • ESP-SHA256-AES256: 592.8 Mbps • ESP-SHA384-AES256: 592.4 Mbps • ESP-SHA512-AES256: 604.5 Mbps OpenVPN 139.1 Mbps L2TP VPN Throughput • Unencrypted: 977.4 Mbps • Encrypted: 334.6 Mbps PPTP VPN Throughput • Unencrypted: 1064.1 Mbps • Encrypted: 206.8 Mbps SSL VPN Throughput 131.6 Mbps 66 Byte Packet forwarding rate 1,453,489 pps / 1,453,488 pps 1,518 Byte Packet forwarding rate 81,279 pps / 81,275 pps
BASIC FUNCTIONS	WAN Connection Type • Static IP • Dynamic IP • PPPoE(supports MRU Configuration) • PPTP • L2TP MAC Clone Modify WAN/LAN MAC Address (LAN MAC Address can be modified only in Standalone Mode) DHCP • DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP IPv6 StaticIP/SLAAC/DHCPv6/PPPoE/6to4Tunnel/PassThrough/Non-Address mode VLAN 802.1Q VLAN IPTV IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
ADVANCED FUNCTIONS	Advanced Routing • Static Routing • Policy Routing • RIP (available in Standalone Mode) • OSPF (available in Standalone Mode) Bandwidth Control IP-based Bandwidth Control Load Balance • Intelligent Load Balance • Application Optimized Routing • Link Backup (Timing, Failover) • Online Detection NAT • One-to-One NAT • Multi-Net NAT • Port Forwarding • Port Triggering§ • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP Session Limit IP-based Session Limit VPN GRE √ (Only in Standalone Mode) SSL VPN 50 Tunnels IPsec VPN • 100 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm • IPsec Failover • IKE v1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS) PPTP VPN • PPTP VPN Server • PPTP VPN Client (10) • 50 Tunnels • PPTP with MPPE Encryption L2TP VPN • L2TP VPN Server • L2TP VPN Client (10) • 50 Tunnels • L2TP over IPSec OpenVPN • OpenVPN Server • OpenVPN Client (5)** • 55 OpenVPN Tunnels • "Certificate + Account" Mode • Full Mode WireGuard VPN • 20 Tunnels
SECURITY	Access Control Source/Destination IP Based Access Control Filtering • WEB Group Filtering§ • URL Filtering • Web Security§ ARP Inspection • Sending GARP Packets • ARP Scanning§ • IP-MAC Binding Attack Defense • TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN
AUTHENTICATION	Web Authentication • No Authentication • Simple Password* • Hotspot (Local User /Voucher/ SMS/Radius) • External Radius Server • External Portal Sever<* • LDAP§
MANAGEMENT	Omada App Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Centralized Management • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller Cloud Access Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Service Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) Maintenance • Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute) (only in Standalone Mode) • NTP Synchronize (only in Standalone Mode) • Port Mirroring • CLI (only in Standalone Mode) • Syslog Support Zero-Touch Provisioning Yes. Requires the use of Omada Cloud-Based Controller. Management Features • Automatic Device Discovery* • Batch Configuration* • Batch Firmware Upgrading* • Intelligent Network Monitoring* • Abnormal Event Warnings* • Unified Configuration* • Reboot Schedule*
OTHERS	Certification CE, FCC, RoHS Package Contents • ER7406 • Power Cord • Quick Installation Guide • Rackmount Kit System Requirements • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10 • MAC OS, NetWare, UNIX or Linux Environment • Operating Temperature: 0 °C to 50 °C (32 °F to 122°F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*

TP-Link ER7406 Routers (10G Port, 1 GB DDR4, 128 MB NAND)

Specifications
Reviews

USB Hub Spec
Networking Interfaces	• 1 Gigabit SFP WAN/LAN Port • 1 Gigabit WAN Port • 4 Gigabit LAN/WAN Ports • 1 USB 3.0 Port (supports USB LTE dongle and USB storage)
Networking Specifications
Networking Antennas	-
Networking Frequency	1.7 GHz
Networking Operation mode	Routers
