Name: D-Link DGS-1100-10MPP Managed Switches (10 Port, Easy to Deploy, Traffic Optimization)
Brand: D-Link
SKU: DGS-1100-10MPP
Price: 1299.00 MYR
Availability: InStock

D-Link DGS-1100-10MPP Managed Switches (10 Port, Easy to Deploy, Traffic Optimization)

Hot

Description

PRODUCT DESCRIPTION

D-Link DGS-1100-10MPP Managed Switches

10 Port | Easy to Deploy | Surveillance Traffic Optimization

* Please Call for order to make sure stock are ready. *
* Images & product color may vary from actual products.*
*All Prices Exclude delivery/installation/activation fees.*

PACKAGE CONTENTS

Switches

ADDITIONAL INFORMATION

View Official Website

Warranty
- D-Link Lifetime Warranty
- Manufactured and warranty provided by D-LInk

SPECIFICATIONS

Model	DGS-1100-10MPP
Technical Specifications	Technical Specifications General Hardware Version • Rev. C Size • DGS-1100-10MPP: • 11-inch desktop size1 • 1U height Number of Ports • DGS-1100-10MPP: • 8 x 10/100/1000 Mbps PoE • 2 x SFP 1000 Mbps Port Functions • IEEE 802.3 compliant • IEEE 802.3u compliant • IEEE 802.3ab compliant • IEEE 802.3af/802.3at compliant • IEEE 802.3bt (DGS-1100-10MPP/26MPP only) • IEEE 802.3x Flow Control supports full-duplex mode • Supports manual/auto MDI/MDIX configuration • Auto-negotiation • Supports half/full-duplex operation • IEEE 802.3az compliant
Performance	Switching Capacity • DGS-1100-10MPP: 20 Gbps Maximum Forwarding Rate • DGS-1100-10MPP: 14.88 Mpps MAC Address Table Size • DGS-1100-10MPP: 8K Entries Packet Buffer • DGS-1100-10MPP: 4.1 Mb Flash Memory • DGS-1100-10MPP: 32 MBytes
Power over Ethernet	PoE Standard • DGS-1100-10MPP: IEEE 802.3af/802.3at/802.3bt PoE Capable Ports • DGS-1100-10MPP: Ports 1 to 8 PoE Power Budget • DGS-1100-10MPP: • 242W total • 30W max. per PoE port for ports 1 to 6 • 90W max. per PoE port for ports 7 to 8
Power Consumption	Standby Mode • DGS-1100-10MPP: 10.4W Maximum Power Consumption • DGS-1100-10MPP: • 250.85 W (PoE on) • 10.45 W (PoE off)
Physical & Environmental	Power Input • 100 to 240 VAC • 50 to 60 Hz • Internal Power Supply 100 to 240 VAC MTBF • DGS-1100-10MPP: 386,307 hours Acoustics • DGS-1100-10MPP: 45.4 dB(A) Heat Dissipation • DGS-1100-10MPP: 570.51 BTU/hr Weight • DGS-1100-10MPP: 1.67 kg (3.68 lbs) Dimensions (W x D x H) • DGS-1100-10MPP: • 294 x 180 x 44 mm • (11.57 x 7.08 x 1.73 in) Ventilation • DGS-1100-10MPP: 1 x Fan Operating Temperature -5 to 50 °C (23 to 122 °F) Storage Temperature -40 to 70 °C (-40 to 158 °F) Operating Humidity 0% to 95% non-condensing Storage Humidity 0% to 95% non-condensing EMI Certifications FCC/IC, CE, VCCI, BSMI, CCC Safety cUL, UL, LVD, CB, CCC, BSMI Software Features - All Models VLAN • Port-based VLAN • 802.1Q Tagged VLAN • Auto Surveillance VLAN • Voice VLAN • Management VLAN • Asymmetric VLAN • VLAN Group • Supports 128 static VLAN groups • Max. 4094 VIDs L2 Features • Flow Control • 802.3x Flow Control • HOL Blocking Prevention • Jumbo Frames up to 9216 Bytes • IGMP Snooping • IGMPv1/v2/v3 Snooping • Supports 64 Groups • IGMP Snooping Querier • 802.3ad Link Aggregation: • DGS-1100-10MPP: Support 5 groups/device and 8 ports/group • Ethernet Ring Protection Switching • G.8032 ERPS • Loopback Detection • Cable Diagnostics • LLDP • Port Mirroring • One-to-One • Many-to-One • Statistics • Tx Ok • Tx Error • Rx Ok • Rx Error • Spanning Tree Protocol • 802.1D STP • 802.1w RSTP • L2 Multicast • MLD Snooping Quality of Service (QoS) • 802.1p Quality of Service • 4 queues per port • Queue Handling • Strict • Weighted Round Robin (WRR) • Port-based Bandwidth Control (Rate Limiting) • Ingress: 8 Kbps • Egress: 64 Kbps Security • D-Link Safeguard • Traffic Segmentation • Broadcast/Multicast/Unknown Unicast Storm Control • DoS Attack Prevention • SSL Management • Web-Based GUI: • Supports IPv4/IPv6 • Client-based Utility (D-Link Network Assistant Utility Green Technolgy • Power Saving by: • Link Status • LED Shut-off • Port Shut-off • System hibernation • Compliant with IEEE 802.3az Energy Efficient Ethernet MIB/RFC Standards • RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC1907 SNMPv2 MIB • RFC1215 MIB Traps Convention • RFC2233 Interface Group MIB • RFC2665 Ether-like MIB • RFC4363 IEEE 802.1p MIB • ZoneDefense MIB • Private MIB • RFC951 BootP client • RFC1542 BootP/DHCP client • RFC2236 IGMP Snooping Ordering Information DGS-1100-10MPP 8-Port 10/100/1000 Mbps + 2-Port SFP 1000 Mbps PoE switch • Lifetime Warranty2
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*
