Name: TP-Link TL-SG105PP-M2 Unmanaged Switch (5-Port, 5× 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps RJ45 ports)
Brand: TP-Link
SKU: TL-SG105PP-M2
Price: 799.00 MYR
Availability: InStock

TP-Link TL-SG105PP-M2 Unmanaged Switch (5-Port, 5× 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps RJ45 ports)

Description

PRODUCT DESCRIPTION

TP-Link TL-SG105PP-M2 Unmanaged Switch

5-Port | 5× 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps RJ45 ports

* Please Call for order to make sure stock are ready. *
* Images & product color may vary from actual products.*
*All Prices Exclude delivery/installation/activation fees.*

PACKAGE CONTENTS

Switches

ADDITIONAL INFORMATION

View Official Website

Warranty
- 3 Years TP-Link Warranty
- Manufactured and warranty provided by TP-Link

SPECIFICATIONS

Model	TL-SG105PP-M2
HARDWARE FEATURES	Interface • 5× 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps RJ45 ports • AUTO Negotiation • AUTO MDI/MDIX Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) Fan Quantity Fanless External Power Supply External Power Adapter (Output: 53.5 VDC / 2.43 A) Packet Forwarding Rate 18.6 Mpps PoE Ports (RJ45) • Standard: 802.3 af/at/bt type3 compliant • PoE++ Ports: Ports 1–4 • Power Supply: 123 W Mac Address Table 4K Switching Capacity 25 Gbps Dimensions ( W x D x H ) 8.2×4.9×1.0 in (209×126×26 mm) Max Power Consumption • 7.57 W (220/50 Hz. no PD connected) • 143.37 W (220/50 Hz. with 123 W PD connected) Max Heat Dissipation • 25.81BTU/h (220 V/50 Hz with no PD connected) • 488.89 BTU/h (220 V/50 Hz with 123W PD connected)
SOFTWARE FEATURES	Advanced Features • Compatible With IEEE 802.3af/at/bt type3 Compliant PDs • Mac Address Auto-Learning And Auto-Aging • IEEE 802.3x Flow Control • 802.1p/DSCP QoS • IGMP Snooping • PoE Auto Recovery (Ports 1-4) Transfer Method Store-And-Forward
OTHERS	Certification FCC, CE, RoHS Package Contents • TL-SG105PP-M2 • Power Adapter • Installation Guide • Rubber Feet Environment • Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*
