Name: TP-Link T2500G-10TS (TL-SG3210) L2 Managed Switch (8-Port, 8 10/100/1000Mbps RJ45 Ports)
Brand: TP-Link
SKU: T2500G-10TS (TL-SG3210)
Price: 699.00 MYR
Availability: InStock

TP-Link T2500G-10TS (TL-SG3210) L2 Managed Switch (8-Port, 8 10/100/1000Mbps RJ45 Ports)

Description

PRODUCT DESCRIPTION

TP-Link T2500G-10TS (TL-SG3210) L2 Managed Switch

8-Port | 8 10/100/1000Mbps RJ45 Ports | 2 Gigabit SFP Slots

* Please Call for order to make sure stock are ready. *
* Images & product color may vary from actual products.*
*All Prices Exclude delivery/installation/activation fees.*

PACKAGE CONTENTS

Switches

ADDITIONAL INFORMATION

View Official Website

Warranty
- 3 Years TP-Link Warranty
- Manufactured and warranty provided by TP-Link

SPECIFICATIONS

Model	T2500G-10TS (TL-SG3210)
Hardware Features
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p
Interface	8 10/100/1000Mbps RJ45 ports (Auto Negotiation/Auto MDI/MDIX) 2 Gigabit SFP Slots 1 RJ45 Console Port 1 Micro-USB Console Port
Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m) 1000BASE-X: MMF, SMF
Fan Quantity	Fanless
Power Supply	100～240VAC, 50/60Hz
Dimensions ( W x D x H )	11.6 × 7.1 × 1.7 in. (294 × 180 × 44 mm)
Mounting	Rack Mountable
Max Power Consumption	8.38W (220V/50Hz)
Max Heat Dissipation	28.59 BTU/h
Performance
Bandwidth/Backplane	20Gbp
Packet Forwarding Rate	14.9Mpps
MAC Address Table	8k
Packet Buffer Memory	4Mb
Jumbo Frame	10KB
Software Features
Quality of Service	Support 802.1p CoS/DSCP priority Support 4 priority queues Queue scheduling: SP, WRR, SP+WRR Port/Flow- based Rate Limiting Voice VLAN
L2 Features	IGMP Snooping v1/v2/v3 MLD v1/v2 Snooping 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group) Spanning Tree STP/RSTP/MSTP Port isolation BPDU filtering/guard TC/Root protect Loop back detection 802.3x Flow Control LLDP/LLDP-MED DHCP VLAN Relay L2PT
VLAN	Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs) MAC/Protocol-based VLAN GARP/GVRP VLAN VPN (QinQ) Management VLAN configuration
Access Control List	L2～L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID; Time Range Based
Security	IP-MAC-Port-VID Binding AAA DHCP Snooping IEEE 802.1X Port/MAC Based authentication, Radius, Guest VLAN DoS Defend Dynamic ARP inspection (DAI) SSH v1/v2 SSL v2/v3/TLSv1 Port Security Broadcast/Multicast/Unknown-unicast Storm Control PPPoE
IPv6	Dual IPv4/IPv6 stack Multicast Listener Discovery (MLD) Snooping IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6
IPv6 Applications	DHCPv6 Client Ping6 Tracert6 Telnet(v6) IPv6 SNMP IPv6 SSH IPv6 SSL Http/Https IPv6 TFTP
Management	Web-based GUI and CLI management SNMP v1/v2c/v3,compatible with public MIBs and TP-LINK private MIBs RMON (1, 2, 3, 9 groups) DHCP/BOOTP Client,DHCP Snooping,DHCP Option82 CPU Monitoring Port Mirroring Dual Image Time Setting: SNTP Integrated NDP/NTDP feature Firmware Upgrade: TFTP & Web System Diagnose: VCT SYSLOG & Public MIBS
Others
Certification	CE, FCC, RoHS
System Requirements	Microsoft® Windows® 10, 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux.
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*
