Name: TP-Link EAP235-WALL Access Point (1200Mbps Wireless AC, 2× Internal Antennas)
Brand: TP-Link
SKU: EAP235-WALL
Price: 429.00 MYR
Availability: InStock

TP-Link EAP235-WALL Access Point (1200Mbps Wireless AC, 2× Internal Antennas)

Description

PRODUCT DESCRIPTION

TP-Link EAP235-WALL Access Point

1200Mbps Wireless AC | 2× Internal Antennas | 300 Mbps at 2.4 GHz + 867 Mbps at 5 GHz

* Please Call for order to make sure stock are ready. *
* Images & product color may vary from actual products.*
*All Prices Exclude delivery/installation/activation fees.*

PACKAGE CONTENTS

Router

ADDITIONAL INFORMATION

View Official Website

Warranty
- 3 Years TP-Link Warranty
- Manufactured and warranty provided by TP-Link

SPECIFICATIONS

Model	EAP230-WALL
HARDWARE FEATURES	Interface Uplink: 10/100/1000 Mbps Ethernet Port1 Downlink: 10/100/1000 Mbps Ethernet Port3 (One port supports PoE OUT. The PoE OUT feature requires 802.3at PoE+ input and the maximum output is 13W.) Physical Security Lock Yes Button Reset Power Supply 802.3af/802.3at PoE Power Consumption 9.8 watts /24.4 watts (PoE Out Included) Dimensions 143 × 86 × 20mm (5.6 × 3.4 × 0.8 in) Antenna 2 Dual-Band Antennas 2.4GHz: 24dBi 5GHz: 24dBi Mounting Wall Plate Mounting
WIRELESS FEATURES	Wireless Standards IEEE 802.11a/b/g/n/ac Frequency 2.4GHz and 5GHz Signal Rate 5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps Wireless Functions 16 SSIDs（Up to 8 SSIDs on each band） Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) MU-MIMO Band Steering Beamforming Load Balance Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client Wireless Security Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Local LAN port based VLAN Rogue AP Detection 802.1X Support 64/128/152-bit WEP, WPA/WPA2-PSK, WPA/WPA2-Enterprise Transmission Power CE: ≤20 dBm (2.4 GHz, EIRP) ≤23 dBm (5 GHz, EIRP) FCC: ≤21 dBm (2.4 GHz) ≤21 dBm (5 GHz)
MANAGEMENT	Omada Cloud Access Yes Omada App Yes Omada Cloud Controller Yes Centralized Management • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller Omada Controller Software Yes Cloud Access Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) Email Alerts Yes LED ON/OFF Control Yes Management MAC Access Control Yes SNMP v1,v2c System Logging Local/Remote Syslog Local/Remote Syslog SSH Yes Web-based Management HTTP/HTTPS L3 Management Yes Multi-site Management Yes Management VLAN Yes
OTHERS	Certification CE, FCC, RoHS System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 Environment Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*

TP-Link EAP235-WALL Access Point (1200Mbps Wireless AC, 2× Internal Antennas)

Specifications
Reviews

USB Hub Spec
Networking Interfaces	Uplink: 1× Gigabit RJ45 Port; Downlink: 3× Gigabit RJ45 Port
Networking Specifications
Networking Antennas	2× Internal Antennas
Networking Frequency	2.4 GHz and 5 GHz
Networking Operation mode	Routers
