Name: TP-Link EAP230-WALL Access Point (1200Mbps Wireless AC, 2 Dual-Band Antennas, 2.4 GHz and 5 GHz)
Brand: TP-Link
SKU: EAP230-WALL
Price: 339.00 MYR
Availability: InStock

TP-Link EAP230-WALL Access Point (1200Mbps Wireless AC, 2 Dual-Band Antennas, 2.4 GHz and 5 GHz)

Description

PRODUCT DESCRIPTION

TP-Link EAP230-WALL Access Point

1200Mbps Wireless AC | 2 Dual-Band Antennas | 2.4 GHz and 5 GHz

* Please Call for order to make sure stock are ready. *
* Images & product color may vary from actual products.*
*All Prices Exclude delivery/installation/activation fees.*

PACKAGE CONTENTS

Router

ADDITIONAL INFORMATION

View Official Website

Warranty
- 3 Years TP-Link Warranty
- Manufactured and warranty provided by TP-Link

SPECIFICATIONS

Model	EAP230-WALL
Hardware Features
Interface	Uplink: 10/100/1000 Mbps Ethernet Port1 Downlink: 10/100/1000 Mbps Ethernet Port1
Physical Security Lock	No
Button	LED/Wi-Fi Button, RESET
Power Supply	802.3af/802.3at PoE
Power Consumption	7 W
Antenna	2 Dual-Band Antennas 2.4GHz: 24 dBi 5GHz: 23.6 dBi
Dimensions ( W x D x H )	3.4 × 3.4 × 1.2 in (86.8 × 86.8 × 30.2 mm)
Mounting	Wall Plate Mounting
Hardware Watch Dog	Yes
Wireless Features
Frequency	2.4GHz and 5GHz
Wireless Standards	IEEE 802.11n/g/b/ac
Signal Rate	5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps
Transmit Power	CE: ≤20 dBm (2.4 GHz, EIRP) ≤23 dBm (5 GHz, EIRP)
Wireless Functions	16 SSIDs（Up to 8 SSIDs on each band） Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) Load Balance Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client MU-MIMO Band Steering Beamforming
Wireless Security	Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Local LAN port based VLAN Rogue AP Detection 802.1X Support 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK
MANAGEMENT
Omada App	Yes
Omada Cloud Access	Yes
Omada Cloud Controller	Yes
Centralized Management	• Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller
Omada Controller Software	Yes
Cloud Access	Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Email Alerts	Yes
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
SNMP	v1,v2c
System Logging Local/Remote Syslog	Local/Remote Syslog
SSH	Yes
Web-based Management	HTTP/HTTPS
L3 Management	Yes
Multi-site Management	Yes
Management VLAN	Yes
OTHERS
Certification	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Environment	Operating Temperature: 0-40 ℃ (32-104 ℉) Storage Temperature: -40-70 ℃ (-40-158 ℉) Operating Humidity: 10-90% non-condensing Storage Humidity: 5-90% non-condensing
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*

TP-Link EAP230-WALL Access Point (1200Mbps Wireless AC, 2 Dual-Band Antennas, 2.4 GHz and 5 GHz)

Specifications
Reviews

USB Hub Spec
Networking Interfaces	Uplink: 10/100/1000 Mbps Ethernet Port1 Downlink: 10/100/1000 Mbps Ethernet Port1
Networking Specifications
Networking Antennas	2 Dual-Band Antennas
Networking Frequency	2.4 GHz and 5 GHz
Networking Operation mode	Routers
